Specifications
3–2
1502C MTDR Service Manual
Characteristic Performance Requirement Supplemental Information
Cursor Ohms Readout
Range
Resolution
Accuracy
1
W
to 1 k
W
3 significant digits
"
10% with serial cable impedance
correction (relative impedance
measurements
"
2%)
Horizontal
Scales
Range
0.1 ft/div to 200 ft/div (0.025 m/div to 50 m/div)
11 values, 1, 2, 5 sequence
1 ft to 2,000 ft (2.5 m to 500 m)
Horizontal Position Any distance to full scale can be moved on
screen
Vp
Range
Resolution
Accuracy
Within
"
1%
Propagation velocity relative to air
0.30 to 0.99
0.01
Custom Option Port Tektronix Chart Recorders YT–1 and YT–1S are
designed to operate with the 1502C. Produces a
high resolution thermal dot matrix recording of
waveform and switch values.
Line Voltage 115 VAC (90 to 132 VAC) 45 to 440 Hz, or
230 VAC (180 to 250 VAC) 45 to 440 Hz, or
12 VDC through battery pack connector
Fused at 0.3 A
Fused at 0.15 A
Battery
Operation
Full Charge Time
Overcharge Protection
Discharge Protection
Charge Capacity
Charge Indicator
5 hours minimum, 20 chart recordings maximum +15° C to +25° C charge and discharge temp,
LCD backlight off. Operation of instrument with
backlight on or at temps below +10° C will
degrade battery operation specification
20 hours maximum
Limited to 10 days continuous charge. Battery
will charge whenever instrument is plugged in.
Battery can be removed during AC operation.
Operation terminates prior to cell reversal
2 Amp-hours typical
Bat/low will be indicated on LCD when capacity
reaches approximately 10%
