SDI7 Dual Channel SD/HD/3G SDI Video Generator module remote commands
:OUTPut<1|2>:
EAUDio:<A|B>GROup[n]:CHANnel [x]:ORIGin?
Returns the channel origin ID string for the specified channel (1-4) of the
specified embedded audio group (1-4) of the specified virtual link (A or B).
:OUTPut<1|2>:FRAMe:SELect <st ring>
Loads the selected fra me picture pattern into memory for the specified
generator output. The string argument is the name of a bitmap file found in
the SDI7/PICTURE directory.
:OUTPut<1|2>:MODe MD_SD|MD_10 80_HD|MD_720_HD|
MODE_3GA|MD_720_3GA|MODE_3 GB| MODE_3GA_2K|MODE_3GB_2K|
MD_2X1080_HD|MD_2X720_HD
Sets the output mode for the selected generator output. The options are as
follows:
MD_SD Standard Definition (270 Mb/s)
MD_1080_HD
High Definition (1.5 Gb/s), 1080 lines
MD_720_HD
High Definition (1.5 Gb/s),720 lines
MODE_3GA 3 Gb/s Level A, 1080 lines
MD_720_3GA 3 Gb/s Level A, 720 lines
MODE_3GB 3 Gb/s Level B, 1080 lines
MODE_3GA_2K 3 Gb/s Level A, 2K (2048 1080)
MODE_3GB_2K 3 Gb/s Level A, 2K (2048 1080)
MD_2X1080_HD
3 Gb/s "dual-stream" (2 HD), 1080 lines
MD_2X720_HD
3 Gb/s "dual-stream" (2 HD), 720 lines
:OUTPut<1|2>:MODe?
Returns the current output mode for the selected generator output.
:OUTPut<1|2>:MOVe:HORizont al <NR1>
Sets the amount of horizontal scrolling in the moving picture mode for the
selected generator output. You can set the value from -252 to +252 samples
in increments of"4 samples.
:OUTPut<1|2>:MOVe:HORizont al?
Returns the amount of horizontal scrolling in the moving picture mode.
:OUTPut<1|2>:MOVe:VERTical <N R1>
Sets the amount o f vertical scrolling in the moving picture mode for the
selected generator output. You can set the value from -252 to +252 lines in
increments of"1 line.
:OUTPut<1|2>:MOVe:VERTical ?
Returns the amount of vertical scrolling in the moving picture mode.
Draft
TG8000 Multiformat Test Signal Generator Programmer Manual 159
