Tektronix TG8000 Programmer's Manual

SDI7 Dual Channel SD/HD/3G SDI Video Generator module remote commands
FRM_PULSE: For
progressive formats, this option selects a pulse per video
frame (high during vertical blanking). For interlaced or segmented frame
formats, this option selects a field square wave signal.
LINE_PULSE: Pulse once per video line.
:OUTPut<1|
2>:TRIgger?
Returns the current signal type at the TRIGGER output c onnector.
:OUTPut<1|2>:VIDeo:Y:STATe <B oolean>
Enables or disables the Y component for the active video signal. When
disabled, blanking (0%) values are used for this component. For GBR
formats, this command affects the G component.
:OUTPut<1|2>:VIDeo:Y:STATe ?
Returns the current signal output state of the Y component for the specified
generator output.
:OUTPut<1|2>:VIDeo:PB:STAT e <Boolean>
Enables or disables the P
B
component for the active video signal. When
disabled, blanking (0%) values are used for this component. For GBR
formats, this command affects the B component.
:OUTPut<1|2>:VIDeo:PB:STAT e?
Returns the current signal output state of the P
B
component for the specified
generator output.
:OUTPut<1|2>:VIDeo:PR:STAT e <Boolean>
Enables or disables the P
R
component for the active video signal. When
disabled, blanking (0%) values are used for this component. For GBR
formats, this command affects the R component.
:OUTPut<1|2>:VIDeo:PR:STAT e?
Returns the current signal output state of the P
R
component for the specified
generator output.
:OUTPut<1|2>:VIDeo:EDH:STA Te <Boolean>
Enables or disables the insertion of Error Detection and Handling (EDH)
ancillary data packets, per SMPTE RP165. This setting is only applicable for
standard definition formats.
:OUTPut<1|2>:VIDeo:EDH:STA Te?
Returns the current setting for EDH insertion.
:OUTPut<1|2>:VIDeo:AVTimin g:STATe <Boolean>
Draft
TG8000 Multiformat Test Signal Generator Programmer Manual 167
