ATG7 Analog Test Generator module
The following t
able lists the ATG7 signal sets that are assigned to the test signal
buttons and shows the test signals that are available in each signal set. The list of
available signals changes depending on the selected signal format.
Table 3-5: ATG7 module signal sets assigned to the test signal buttons
Button name Signal set Signals in the signal set
NTSC and NTSC No Setup formats
COLOR BAR Color Bars 100% Color Bars, 75% Color Bars, SMPTE Color
Bars
LINEARITY Linearity
5 Step, 10 Step, Modulated 5 Step, Modulated
Pedestal, Modulated Ramp, Ramp, Shallow Ramp
FLAT FIELD Flat Fields
0% Flat Field (NTSC format only), 10% Flat Field,
40% Flat Field, 50% Flat Field, 100% Flat Field,
Field Square Wave, Black Burst, Black Burst with
Field Ref
MULTIBURST
Multiburst
100% Multiburst, 60% Mult iburst, Multipulse
SWEEP Sweep 100% Sweep, 60% Sweep, Chroma Frequency
Response
MONITOR
Monitor
100% Red Field, 75% Red Field, 2 Level Pedestal
& Pluge, 4 Level Pedestal & Pluge, Convergence
Pattern, Grey W indow, White Window, Safe Area,
Monitor Setup
PULSE BAR Pulse & Bar Window 2T Pulse & Bar, Sin X/X
OTHER Other FCC Composite, FCC Multiburst, NTC7
Combination, NTC7 Composite, Matrix 1, SNG
Color Bars
PAL format
COLOR BAR Color Bars 100% Color Bars, 75% Color Bars, 100% Color
Bars Over Red, 75% Color Bars Over Red
LINEARITY Linearity
5 Step, 10 Step, Modulated 5 Step, Modulated
10 Step, Modulated Pedestal, Modulated Ramp,
Ramp, Shallow Ramp
FLAT FIELD Flat Fields
40% Flat Field, 50% Flat Field, 100% Flat Field,
Field Square Wave, Black Burst, Black Burst with
No Field Ref, Field Square Wave
MULTIBURST
Multiburst
100% Multiburst, 60% Mult iburst, Multipulse
SWEEP Sweep 100% Sweep, 60% Sweep
MONITOR
Monitor
100% Red Field, 75% Red Field, 2 Level Pedestal
& Pluge, 4 Level Pedestal & Pluge, Convergence
Pattern, Grey W indow, White Window, Safe Area,
Monitor Setup Matrix
PULSE BAR Pulse & Bar 2T Pulse & Bar, Sin X/X
OTHER Other CCIR 17, CCIR 18, CCIR 330, CCIR 331, UK ITS 1,
UK ITS 2 , UK 1 Line ITS, ITS Matrix 1
3–20 TG8000 Multiformat Test Signal Generator User Manual
