HDVG7 HDTV Digital Video Generator module
HDVG7 module m
ain menu
Use the HDVG7 module main menu to perform the following tasks:
Set the logo, text, or circle overlay on the output signal.
Set the timing o ffset on the output signals.
Scroll the active p icture area of the output signal.
Enable or d
isable the output and set parameters for each embedded audio
group.
Enable or
disable the Y, Pb, and/or Pr components on the video output signal.
3–232 TG8000 Multiformat Test Signal Generator User Manual
