Tektronix TG8000 User Manual

SDI7 Dual Channel SD/HD/3G SDI Video Generator module
SDI7 module fa
ctory default settings
The following table shows the factory default settings for the SDI7 module.
These settings are recalled when you select Factory Default from the PRESET :
RECALL menu i
tem in the mainframe main menu.
Table 3-69: SDI7 module factory default settings
Menu item name Settings
TEST SIGNAL 100% Color Bars
FORMAT
1080 59.94i
SAMPLE STRUCTURE/DEPTH YCbCr 4:2:2 10b
OUTPUT MODE HD (1920 × 1080)
MOVING PICTURE
H Step 0 Sample(s)
V Step 0 Line(s)
Period
1Frame(s)
Random Disable
OVERLAY : LOGO
Status
Disable
Source
NOTE. The default logo is the "first" file in the
SDI7/LOGO directory, as sorted by the date of
the logo file (oldest first). If the factory-provided
logo files are installed, the default logo is
“Tektronix_logo_500x125.bmp.”
However, if the user has removed the
factory-provided logo files and added their own
custom files, then the default logo will be the oldest
file installed in the SDI7/LOGO directory.
XPosition
–5 % APW
YPosition
–5 % AP H
OVERLAY : ID TEXT
Status
Disable
Source
User-entered string
XPosition
5.0 % APW
YPosition
5.0 % APH
Font Size 8.0 % APH
TG8000 Multiformat Test Signal Generator User Manual 3–337
