Tektronix TG8000 User Manual

Preface
This manual describes how to install and operate the TG8000 Multiformat Test
Signal Generator.
Supported products
The information in this manual applies to the following Tektronix products:
TG8000 mainframe (includes the replaceable Power Supply module)
AG7 Audio Generator module
AGL7 Analog Genlock module
ATG7 Analog Test Generator module
AVG7 Ana
log Video Generator module
AWVG7 Analog Wideband Video Generator module
BG7 Black Generator module
DVG7 Digital Video Generator module
GPS7 GPS Synchronization and Timecode module
HD3G7 HD 3 Gb/s SDI Video Generator module
HDLG
7HDDualLinkGeneratormodule
HDVG7 HDTV Digital Video Generator module
SDI7 Dual Channel SD/HD/3G SDI Video Generator module
Ab
out this manual
This manual is composed of the following sections:
Getting started shows you how to configure and install your TG8000 system
andprovidesanIncomingInspectionprocedure. Thesectionalsodescribes
the mainframe options and how to install modules.
Operating basics provides an overview of the front-panel controls and
rear-panel conne ctions.
Modules provides operating information for each of the modules that can
be added to the TG8000 mainframe.
TG8000 Multiformat Test Signal Generator User Manual xxi

Tektronix TG8000 Specifications

General

Brand	Tektronix
Model	TG8000
Category	Portable Generator
Language	English
