DVG7 Digital Video Generator module
DVG7 Digital V
ideo Generator module
This section
describes the module-specific functions of the DVG7 Digital Video
Generator module. Refer to the following locations for additional information
about this module:
DVG7 module connectors for a description of the rear-panel connectors. (See
page 2-12.)
DVG7 module functional check for a basic procedure to check that the module
is functional. (See page 1-25.)
TG8000 Specifications and Performance Verification Technical Reference for
module specifications and for a detailed procedure to verify that the module
is functioning as specified.
TG8000 Programmer Manual for information about the commands to
remotely control the module.
DVG7 module product description
The D VG7 Digital Video Generator module is a digital video generator that
provides NTSC composite digital signals and 525/625 component digital signals.
The module p rovides the following features:
Two serial digital video outputs.
Two serial digital black outputs (Option BK only).
Overlay of circle, text, or logo on the video signal.
Moving picture by scrolling the active picture area of the output signal.
Up
to 16 channels of 24- or 20-bit embedded digital audio with a sample
rate of 48 kHz.
F
ull remote control using Ethernet interface.
TG8000 Multiformat Test Signal Generator User Manual 3–75
