Tektronix TG8000 User Manual

BG7 Black Generator module
BG7modulefac
tory default settings
The following table shows the factory default settings for the BG7 module.
These settings are recalled when you select Factory Default from the PRESET :
RECALL menu i
tem in the mainframe main menu.
Table 3-16: BG7 module factory default settings
Menu item name Settings
OUTPUT : BLACK 1 to BLACK 4
Format
NTSC
SIGNAL
Black Burst
OUTPUT : HD TRI-LEVEL SYNC
RATE
Non-integer
FIELD REFERENCE
1
Disable
TEST SIGNAL
1
Black Burst
TIMING
Vertical
0 Line(s)
Horizontal 0.0000 msec
TIMECODE
2
SOURCE
Disable
30 DROP
Enable Drop Frame
VITC
2
OUTPUT
Disable
VITC 1
Line 14
VITC 2
Line 16
1
The TEST SIGNAL menu item replaces the FIELD REFERENCE menu item on the BLACK 3 and BLACK 4
outputs when the BG7 module has Option CB installed.
2
TheTIMECODEandVITCmenuitemsarepresentonlywhenaGPS7moduleisalsoinstalledinthemainframe.
3–74 TG8000 Multiformat Test Signal Generator User Manual
