Tektronix TG8000 User Manual

AGL7 Analog Genlock module
Horizontal fine
. Use the left (◄)orright(►)arrowbuttontoadjustthefine
horizontal offset. The range of the timing adjustment depends on the selected
signal format. (See Table 3-2.) (See Table 3-3.)
NOTE. You can reset the timing offset to zero by pressing the left (◄)orright(►)
arrow buttons simultaneously.
Table 3-2: Timing adjustment ranges for AGL7 input signals
Format name Line settings Coarse settings (μs) Fine setting s (ns)
NTSC
± 525 ± 63.5556 ± 10.00
PAL ± 1250 ± 64.0000 ± 10.00
1080 60i ± 562 ± 29.6296 ± 10.00
1080 59.94i ± 562 ± 29.6593 ± 10.00
1080 50i ± 562 ± 35.5556 ± 10.00
1080 24sF ± 562 ± 37.0370 ± 10.00
1080 23.98sF ± 562 ± 37.0741 ± 10.00
1080 30p ± 562 ± 29.6296 ± 10.00
1080 29.97p ± 562 ± 29.6593 ± 10.00
1080 25p ± 562 ± 35.5556 ± 10.00
1080 24p ± 562 ± 37.0370 ± 10.00
1080 23.98p ± 562 ± 37.0741 ± 10.00
720 60p ± 375 ± 22.2222 ± 10.00
720 59.94p ± 375 ± 22.2444 ± 10.00
720 50p ± 375 ± 26.6667 ± 10.00
Table 3-3: Timing adjustment ranges for AGL7 output signals
Format name Line settings Coarse settings (μs) Fine settings (ns)
NTSC
± 525 ± 63.5556 ± 10.00
PAL ± 1250 ± 64.0000 ± 10.00
1080 60i ± 562 ± 29.6296 ± 7.00
1080 59.94i ± 562 ± 29.6593 ± 7 .00
1080 50i ± 562 ± 35.5556 ± 7.00
1080 24sF ± 562 ± 37.0370 ± 7.00
1080 23.98sF ± 562 ± 37.0741 ± 7.00
1080 30p ± 562 ± 29.6296 ± 7.00
1080 29.97p ± 562 ± 29.6593 ± 7.00
1080 25p ± 562 ± 35.5556 ± 7.00
1080 24p ± 562 ± 37.0370 ± 7.00
1080 23.98p ± 562 ± 37.0741 ± 7.00
TG8000 Multiformat Test Signal Generator User Manual 3–15
