SDI7 Dual Channel SD/HD/3G SDI Video Generator module
Generates a mov
ing picture by scrolling the active picture area of the output
test signal.
Up to 32 channe
ls of 24-bit embedded digital audio with a sample rate of
48 kHz.
AV Timing mo
de.
Timing adjustment anywhere in the frame for the output.
Timecode generator with ATC-LTC or ATC-VITC.
Full remote control using Ethernet interface.
SMPTE 352M payload identifier.
User-defined ancillary data packet.
HowtooperatetheSDI7module
After the module is installed in the mainframe, and the mainframe is installed in
the rack or other location where it will be used, use the following procedure to
access each function of the module:
1. Connect the power cord to the power connector on the rear panel, and then
plug the cord into the AC electric power source. Electric power is supplied
to the mainframe.
2. Wait until the power-on initialization process is complete, and then check that
no error messages appear on the display.
3. After the initialization process is complete, the mainframe main menu appears
as shown below:
4. For first-time operation only, if you ordered Option 3G and/or DBT as an
upgrade to your existing SDI7 module, you must enter the option key that was
supplied with the upgrade in order to enable the software option(s). (See
p
age 3-254, To enter the option key on the SDI7 module.)
NOTE. If you ordered Option 3G and/or DBT at the same time you ordered the
SDI7 module, the module was shipped from the factory with the option already
enabled.
TG8000 Multiformat Test Signal Generator User Manual 3–253
