Operating basics
PRESET submenu
Use this menu to
recall instrument settings saved as a preset or save the current
instrument settings to a preset. There are 13 user-selectable presets. The first
seven numbered presets can be rec alled using the mainframe GPI (General
Purpose Interface). Use the up (◄) or right (►) arrow button to scroll through the
menu items. (See Figure 2-18.)
The following three p resets are n amed at the factory and have special functions:
Power On Default: Use this preset to save instrument settings that you want
automatically loaded when the TG8000 powers on. If one of the seven presets
is selected in the mainframe GPI (General Purpos e Interface), that preset
takes precedence over this Power On Default preset. You cannot assign this
preset na
me to another preset.
NOTE. If you want to save network parameters to a preset, use the Power On
Default preset.
User Default: Use this preset to save user-specified default settings. If you
save new instrument settings in this preset, a confirmation message appears to
prevent overwriting.
Factory Default: Usethispresettoresetthemainframe and all of the installed
modules to the factory default settings. The following settings are not affected
by the factory default: front-panel timeout, and network parameters.
Figure 2-18: PRESET submenu
TG8000 Multiformat Test Signal Generator User Manual 2–23
