AWVG7 Analog Wideband Video Generator module
AWVG7 Analog W
ideband Video Generator module
This section
describes the module-specific functions of the AWVG7 Analog
Wideband Video Generator module. Refer to the following locations for
additional information about this module:
AWVG7 module connectors for a description of t he rear-panel connectors.
(See page 2-11.)
AWVG7 module functional check for a basic procedure to check that the
module is functional. (See page 1-23.)
TG8000 Specifications and Performance Verification Technical Reference for
module specifications and for a detailed procedure to verify that the module
is functioning as specified.
TG8000 Programmer Manual for information about the commands to
remotely control the module.
AWVG7 module product description
The AWVG7 Analog Wideband Video Generator module is a 30 MHz bandwidth
video signal generator, which provides wideband analog component video signals
for H DTV systems. The module provides the following features:
Supports the following system formats: 1080/60i, 1080/59.94i, 1080/50i,
1080/24sF, 1080/23.98sF, 1080/30p, 1080/29.97p, 1080/25p, 1080/24p,
108
0/23.98p, 720/60p, 720/59.94p, 720/50p, 720/24p, and 720/23.98p.
NOTE. Signals for the following system formats are preinstalled in the mainframe:
1080/60i, 1080/59.94i, 1080/24sF, 1080/23.98sF, 720/60p, and 720/59.94p.
Signals for additional system formats are included on the TG8000 SW Library
and Documentation DVD that is supplied as a standard accessory. Refer to
the TG8000 PC Tools Technical Reference for detailed information on how to
download signal files from the DVD to the TG8000.
Six analog component video outputs.
Outputs a frame picture created by the Frame Picture Generator application.
Overlay of circle, text, or logo on the video signal.
Generates a moving picture by scrolling the active picture area of the output
test signal.
Full remote control using Ethernet interface.
3–48 TG8000 Multiformat Test Signal Generator User Manual
