GPS7 GPS Synchronization and Timecode modu le
Table 3-24: GPS7 module factory default settings (cont.)
Menu item name
Submenu
item name Settings
TIME SETUP
TIME OF DAY menu
Source: GPS Signal
Internal: 2008-01-01 00:00:00
TIME ZONE OFFSET menu
+ 00:00
DST SCHEDULE menu
Enable: Off
PROGRAM TIME menu
Setup: Initial Time: 00:00:00
JAM SYNC menu
Enable: ON
LEAP SECOND menu
Setup: Scheduled Time: 00:00:00
ALARM TIME menu
Enable: Off
Setup: Alarm Time: 00:00:00
SELECT
MENU
ALARM DELAY menu
GPO Loss of Lock: 00:00:10
GPO Signal Warning: 00:00:10
Black 2 Blank On Unlock: 00:00:10
SELECT LTC
INPUT-OUTPU T
(LTC 1 only)
Output (if allowed)
NOTE. INPUT-OUTPUT selection for LTC 1 is
not available on earlier GPS7 modules without the
REF IN input connector.
TYPE
30 fps drop frame
SOURCE Local (DST)
OFFSET
+ 00:00:00:00
TIMING
Delay: 0.00 ms
LTC 1
LTC 2
LTC 3
LTC 4
OUTPUT
LEVEL
Level: 2.0 Volt
SELECT GPIO
INPUT 1
Trigger Select: None
OUTPUT 1
OUTPUT 2
Alarm Select: None
3–156 TG8000 Multiformat Test Signal Generator User Manual
