Tektronix TG8000 User Manual

HD3G7 HD 3 Gb/s SDI Video Generator module
Table 3-39: HD3G7 module factory default settings (cont.)
Menu item name Settings
VIDEO
Y
ON
Cb ON
Cr ON
Edge Filter Enable
AV Timing Mode
OFF
ANC PAYLOAD
Output
Disable
Parity Automatic
DID 0x101
SDID
0x200
DC
0x101
UDW 0x200
CS
0x200
Auto-Calculate CS
Enable
Line 9
Field 1, Line: 9
Field 2, Line: 9
Start Sample
1928
Video Channel
Luma
Link Location Link A
Stream Location HS Stream 1
SMPTE 352 PAYLOAD
Enable
TRIGGER OUTPUT System Clock
SECONDARY OUTPUT
Test Pattern
TG8000 Multiformat Test Signal Generator User Manual 3–213
