Tektronix TG8000 User Manual

SDI7 Dual Channel SD/HD/3G SDI Video Generator module
The following t
ables list the Dolby E loudness measurements for each program.
The measurements were made with a Tektronix WFM8000 Series waveform
monitor using the ATSC A/85 2013 Loudness preset.
Dialnorm values of –23 dB and –24 dB a re used by default within the instrument,
depending on the Dolby E level setting. If you want to use the measured loudness
values instead of the default dialnorm values, you can e nter them by adjusting
the Dolby E metadata d ialnorm setting. If you want to continue using these
measured loudness values, use the PRESET menu to create a preset with the
specificva
lues you want.
Table 3-66: Dolby E loudness measurements – 23.98 and 24 Hz frame rates
Loudness m easurem ent values (LKFS)
Dolby E
program
Dolby E
level
Program 1 Program 2 Program 3 Program 4 Program 5 Program 6 Program 7 Program 8
–20 dBSF
–20.2 –20.2 –20.2 –20.2 –20.2 –20.2 –20.2 –20.2
–18 dBSF
–18.2 –18.2 –18.2 –18.2 –18.2 –18.2 –18.2 –18.2
8x1
Multitone –22.5 –23.9 –25.7 –27.6 –29.6 –30.5 –31.0 –32.2
–20 dBSF
–11.3
–18 dBSF
–9.3
7.1
Multitone –17.2
–20 dBSF
–12.6 –17.2
–18 dBSF
–10.6 –15.2
5.1+2
Multitone –17.5 –28.5
–20 dBSF
–12.6
–18 dBSF
–10.6
5.1
Multitone –17.5
–20 dBSF
–17.2 –17.2 –17.2 –17.2
–18 dBSF
–15.2 –15.2 –15.2 –15.2
4x2
Multitone –20.1 –23.6 –27.0 –28.5
TG8000 Multiformat Test Signal Generator User Manual 3–317
