Tektronix TG8000 User Manual

SDI7 Dual Channel SD/HD/3G SDI Video Generator module
Table 3-69: SDI7 module factory default settings (cont.)
Menu item name Settings
DOLBY-E CONFIG
1
Program 5.1
Level
–18.0 dBFS
Bit Depth 20 bits
Line Position
Ideal (Line xx)
Program 1 Description Tektronix Program 1
Program 2 Description Tektronix Program 2
Program 3 Description Tektronix Program 3
Program 4 Description Tektronix Program 4
Program 5 Description Tektronix Program 5
Program 6 Description Tektronix Program 6
Program 7 Description Tektronix Program 7
Program 8 Description Tektronix Program 8
Dialnorm –23 dB
Line Mode
Film Standard
RF Mode
Film Standard
Center Downmix Level
–3.0 dB
Surround Downmix Level
–3.0 dB
Downmix Preferred
LoRo
LtRt Center Mix Level
–3.0 dB
LtRt Surround Mix Level
–3.0 dB
LoRo Center Mix Level
–3.0 dB
LoRo Surround Mix Level
–3.0 dB
Frame Rate –3.0 dB
TIMING
Vertical
0 Line(s)
Horizontal 0.0000 μs
Relative To
Serial (0H)
TIMECODE
Source Local (DST)
30 Drop Frame Enable
ATC-LTC OFF
ATC-VITC OFF
TG8000 Multiformat Test Signal Generator User Manual 3–339
