2. Technical Description
2.1 Refs. 769501-769502 Gateway Main Functionalities
The Refs. 769501-769502 Gateway is aimed for customer premises and complies with the ITU-T G.984.x recommendation in order to transport
(over GPON) and deliver (to premises domain) the full broadband service pack.
Broadband service applications are commonly referred as below:
High speed internet (HSI);
Voice (VoIP) services (SIP/MEGACO H.248);
TV (whether IPTV or analog RF video overlay);
WI-FI.
The multiplay environment is thus reinforced when combining the upper referred services.
2.2 Application Scenario
The next gure shows a possible gateway scenario for Refs. 769501-769502 equipments when in an end-to-end PON architecture.
Figure 2-1: Refs. 769501-769502 equipment application scenario
