183

7.2.9.2 “cong” command

Name cong

Description Congures multicast

Full path /multicast/cong

Arguments

[OPTIONAL]

--igmp-fast-leave IGMP Fast Leave <enable|disable> (enable by default)

--igmp-last-member-query-int IGMP Last Member Query Interval (10 by default)

--igmp-max-groups IGMP Maximum Multicast Groups (25 by default)

--igmp-max-members IGMP Maximum Multicast Group Members (25 by

default)

--igmp-max-sources IGMP Maximum Multicast Data Sources (for IGMPv3)

(10 by default)

--igmp-query-int IGMP Query Interval (125 by default)

--igmp-query-resp-int IGMP Query Response Interval (10 by default)

--igmp-rv IGMP Robustness value (2 by default)

--igmp-version IGMP Default Version <1|2|3> (2 by default)

--mld-fast-leave MLD Fast Leave <enable|disable> (enable by default)

--mld-last-member-query-int MLD Last Member Query Interval (10 by default)

--mld-max-groups MLD Maximum Multicast Groups (10 by default)

--mld-max-members MLD Maximum Multicast Group Members (10 by

default)

--mld-max-sources MLD Maximum Multicast Data Sources (for MLDv2)

(10 by default)

--mld-query-int MLD Query Interval (125 by default)

--mld-query-resp-int MLD Query Response Interval (10 by default)

--mld-rv MLD Robustness value (2 by default)

--mld-version MLD Default Version <1|2> (2 by default)

--precedence Multicast precedence <Disable|[1,8]>

(lower value, higher priority) (Disable by default)

Table 7-49: “cong” command information

7.2.10 “diagnostics” node

This node allows the user to check the current status of the equipment LAN and WLAN interfaces.

+ diagnostics[@show]

Figure 7-10: diagostics node tree
