GPON ONT
Parameter Description
Tunnel Name
Gre Tunnel identication (string) congured when gre
tunnel is created
Local IP IP address of the local end interface of the GRE tunnel
Remote IP IP address of the local end interface of the GRE tunnel
Tunnel IP Tunnel IP Address
Peer IP Peer IP Address
Tunnel Mask Tunnel mask
TTL Time To Live in seconds
Tunnel Mode Indicates if this is a Layer 2 mode tunnel
Status
Flag (enable/disable); indicate the Tunnel is administra-
tively enabled
Table 5-3: GRE Tunnels Status Table parameters
5.5.3 Statistics
When selected the Device Info sub-menu item Statistics expands into a statistics sub-menu, composed of the following items:
LAN
WAN Service
The main window shows the LAN statistics information.
5.5.3.1 LAN
Selection of the Device Info, Statistics submenu, item LAN displays in the main window the current LAN (Local Area Network) statistics information,
Figure 5-8.
Received and Transmitted Total and per type of trac Statistics will be displayed for each LAN interface with trac. LAN statistics parameter de-
scription can be found in Table 5-4.
Figure 5-8: LAN Statistics
