4.3 How to Setup Refs. 769501-769502
The Refs. 769501-769502 may be installed horizontally on a at surface or wall mounted. Quick steps for these setups are described below.
Wall-mount
Refs. 769501-769502 wall mounting kit consists of two AGL. ZN. CC. PZ. 3,5X30mm screws, standard DIN 7505-B and two Nylon M 6X30 wall an-
chors.
On the back of the Refs. 769501-769502 there are two mounting hole. Refer to Figure 4-4- a) to locate the mounting holes for your
installation;
Mark on the wall the two Refs. 769501-769502 holding screws’ locations;
Drill the holes on the wall with a drill bit size that matches the screws or wall anchors’ size if you are using wall anchors;
Secure the screws on the wall leaving a distance of about 3mm between the screw nut and the wall;
Remove the Refs. 769501-769502 optical adaptor protection cap, Figure 4-4- b);
Clean the Refs. 769501-769502 optical connector face within the optical adaptor with an appropriate optical connector cleaning
material;
Remove the protection cap of one of optical SC/APC connector of optical patchcord;
Clean the optical SC/APC connector face with an appropriate optical connector cleaning material;
Plug the patchcord cleaned SC/APC optical connector on the Refs. 769501-769502 SC/APC adaptor, observing the alignment
mechanism, Figure 4-4- c);
You will hear a click when the connector is secure into place;
Pass the optical patchcord, in a counter- clockwise direction, round the storage circular guide on the back of the equipment, wrap-
ping it round as many times as necessary, Figure 4-4- d). Please avoid small bend radius on the patchcord (30mm minimum bend
radius);
Pass the other end of the optical patchcord to the outside of the equipment using the passing hole, Figure 4-4- f);
Fix the optical patchcord with plastic clamps to the Refs. 769501-769502 the appropriate xing support fastening the plastic clamp
just enough to secure the optical patchcord, Figure 4-4- e);
Hold the Refs. 769501-769502 vertically and align the center of the equipment mounting holes Figure 4-4- a) with the holding
screws in the wall;
Assure the screws enter the mounting holes, Figure 4-4- a);
Slide the equipment vertically down to hold it in place.
