GPON ONT
Connection Description
C1
12V DC Adapter
C2
RJ11 Telephone cable
C3
Ethernet Cable UTP CAT56 cable (direct or crossover)
C4
Single-mode Optical Cable with SC/APC Connector (GPON)
C5 (1)
Cable with F-type Connectors, Coaxial 75 Ohm
W1
WI-FI
NOTES:
(1) Optional ;
Dependent on the Refs. 769501-769502 specic model
Table 4-2: Refs. 769501-769502 connections
