GPON ONT
Parameter Description
Description
WAN service description; String that can be entered by the user; default values indicates
type of WAN service (pppoe/ipoe/gre/br), used layer 2 interface (eg. veip0/eth1) inter-
face and used vlan id (eg. 11)
Type Identies Wan service Type (PPPoE/IPoE/gre/br)
Vlan8021p
IEEE 802.1P Priority value (0 to 7)- to use for tagged services
Set to “-1” for Untagged services
VlanMuxId Used 802.1Q VLAN ID (0-4094) for tagged services; for untagged services use value “-1”
Vlan Tpid VLAN Tag Protocol Identier;
Igmp Proxy
Flag (enable/disable) ; indicates if IGMP proxy is enabled; to use for multicast congura-
tion in the case of IPv4.
Igmp Source
Flag (enable/disable); indicates if IGMP source is enabled; to use for multicast congura-
tion in the case of IPv4.
Igmp Src Enbl
Flag (enable/disable); indicates if IGMP source is enabled; to use for multicast congura-
tion in the case of IPv4.
NAT Flag (enable/disable); Indicates if NAT is enabled
Firewall Flag (enable/disable); Indicates if Firewall is enabled
IPv6 Flag (enable/disable) ; indicates if IPv6 is enabled
MLD Pxy
Flag (enable/disable) ; indicates if MLD proxy is enabled; to use for multicast congura-
tion in the case of IPv6.
MLD Src
Flag (enable/disable) ; indicates if MLD source is enabled; to use for multicast congura-
tion in the case of IPv6.
Remove If selected, the WAN Service can be removed with Remove button
Edit Flag (enable/disable) ; indicates if IPv6 is enabled
Enable/Disable Flag (enable/disable); indicate if the interface is administratively enabled
Table 5-12: WAN Service Setup Table parameters
Parameter Description
Tunnel Name GRE Tunnel identication (string) congured when gre tunnel is created
Local IP IP address of the local end interface of the GRE tunnel
Remote IP IP address of the local end interface of the GRE tunnel
Tunnel IP Tunnel IP Address
Peer IP Peer IP Address
Tunnel Mask Tunnel mask
TTL Time To Live in seconds
Remove If selected, the GRE Tunnel can be removed with Remove button
Tunnel Mode Indicates if this is a Layer 2 mode tunnel
Enable/Disable Flag (enable/disable); indicate the Tunnel is administratively enabled
Table 5-13: GRE Tunnels Setup Table parameters
5.6.2.1 WAN Service Creation
To create a WAN service, use the ADD button in the Advanced Setup WAN service Main window, Figure 5-20. A new window will be displayed
where is possible to select on a combo box the
Refs. 769501-769502 WAN interface associated to the service to create, Figure 5-21. Once
selected the WAN interface use the Next Button, Figure 5-22, to progress to the next WAN service conguration window – Type of service
selection and service conguration, Figure 5-23.
