System Operation
TP04100A Interface
&
Applications
Rev A: 06/1
5/98
For DUT mode test setups, see Section
3-14
on page
3-42.
1
Different test setup files are programmed through the
Program Test Setup Screen
(see Figure
3-12).
By using the factory defaults, or by accessing a previously saved test file, a new file can be programmed by
changing the system setup parameters and the temperature setpoint parameters for a particular test. For a
detailed summary, see Section
3-12.1.
I
I
3-5.4
Self-Tune: DUT Modes
11
Self-tuning allows the system to "learn" and adapt itself successively to match DUT mass for the best
compromise between minimal overshoot and fastest temperature transition time. DUT mode self-tuning is
4
automatic (so long as it is selected on the
Define Parameters Screen:
see Figure
3-1
1)
and optimizes operation
I
by measuring the thermal mass characteristics of the specific DUT against successive system supplied
temperature ranges.
1
Page
3-8
