Rev A: 0611
5/98
Preparation for
Use
TP04100A Interface
&
Applications
2-13
Main Power Connection
The TP04100A interconnections, including IEC 320 power receptacle, are located as pictured on the rear
panel of the Controller (see Figure 2-8).
For "AC Power Standards," see Section 2-6.2. Also, observe the following caution:
CAUTION
3:
Before connecting the TP04100A to its electrical source, check that the
-
(ac) voltage
and frequency to be supplied to the TP04100A are correct for those listed on its data plate (located on
the rear panel of the controller cabinet).
ATTENTION
3:
Se reporter au numkro d'Avertissement ou au numero &Attention appropri6, dans la
section
((
Consignes de sCcuritC
))
au debut de ce manuel.
VORSICHT!
3:
Bitte beziehen Sie sich auf die entsprechende Warnungs- oder Vorsichtsnummer im
Abschnitt iiber Vorsichtsmal3regeln
am
Anfang dieses Handbuchs.
PRECAUCION
3:
Vea el numero de la Advertencia o Precaucidn en la secci6n de "Precauciones de
Seguridad", a1 comienzo de este manual.
1.
The TP04100A includes a standard, 2.4 meter (8 feet) long line cord,
and
IEC 320 male power connector
socket.
2-14
Air Connections
See Figure 2-8, "System Input/Output (Rear Panel)," for compressed air input fitting SP1 (Supply Pressure
I), located on the Controller cabinet rear panel.
For "Compressed Air Standards" required for system operation, see Section 2-6.3.
The TP04100A is supplied with a 3.7 meter (12 feet) iong, 318 inch inside diameter, nylon tubing which is
used to connect between the System air FilterRegulator assembly and the System rear panel. Supplies to
connect between the System filter assembly and the facility compressed air supply must be provided by the
customer.
Interconnect the compressed air supply as follows.
1. Locate the air Filter/Regulator Assembly (supplied separately
as
SA 133 10) in
a
convenient place
between the user-supplied compressed air source and the Controller rear panel. Attach the mounting
bracket of the FilterRegulator Assembly to a secure surface with two mounting screws (not supplied).
See Section
5,
"Air Filter Element Servicing" for a description of and drawing of the System air
FilterIRegulator Assembly.
Page 2-2
1
