Terex Genie GS84D-401 User Manual

June 2021 Service and Repair Manual
Deutz D 2.9 L4 Engine Fault Codes
Part No. 1306587GT GS
™
-84 • GS
™
-90 139
SPN = Suspect Parameter Number
FMI = Failure Mode Identifier
KWP = Keyword Protocol
SPN
FMI
KWP
Description
523988
3
1245
Charging
lamp; short circuit to
battery
523988
4
1246
Charging lamp; short circuit to
ground
523988
5
1243
Charging lamp; open load
523988
12
1244
Charging lamp; over temp.
523998
4
1327
Injector cylinder bank
2 slave;
short circuit
523999
12
1328
Injector p
owerstage output Slave
defect
524014
1
1254
Air pressure glow plug flush
line;
below limit
524016
2
1259
Amount of air is not plausible to
pump speed
524016
2
1260
Calculated amount of air is not
plausible to HFM reading
524016
11
1258
HFM sensor; elec
trical fault
524021
11
1263
Burner fuel line pipe leak behind
Shut Off
Valve
524024
11
1302
Deviation of the exhaust gas
temp. setpoint to actual value
downstream (DOC) too high
524028
2
1431
CAN message PROEGRActr;
plausibility error
524029
2
1432
Tim
eout Error of CAN-Receive-
Frame ComEGRActr
- exhaust
gas
recirculation positioner
524030
7
1440
EGR actuator; internal error
524031
13
1441
EGR actuator; calibration error
SPN
FMI
KWP
Description
524032
2
1442
EGR actuator; status message
EGRCust
is missing
524033
7
1443
EGR actuator; due to
overload in
Save Mode
524034
3
1438
Disc separator; short circuit to
battery
524034
4
1439
Disc separator; short circuit to
ground
524034
5
1436
Disc Separator; open load
524034
12
1437
Disc Separator; p
owerstage over
temperature
524035
12
1341
Injector diagnostics; time out
error in the SPI communication
524057
2
1505
Electric fuel pump; fuel pressure
build up error
524097
9
1663
Timeout error of CAN
-Transmit-
Frame DPFBrnAirPmpCtl
524098
9
1664
Timeo
ut error of CAN-Transmit-
Frame ComDPFBrnPT
524099
9
1665
Timeout error of CAN
-Transmit-
Frame ComDPFC1
524100
9
1666
Timeout error of CAN
-Transmit-
Frame ComDPFHisDat
524101
9
1667
Timeout error of CAN
-Transmit-
Frame ComDPFTstMon
