Terex Genie GS84D-401 User Manual

Service and Repair Manual June 2021
Deutz D 2.9 L4 Engine Fault Codes
140 GS
™
-84 • GS
™
-90 Part No. 1306587GT
SPN = Suspect Parameter Number
FMI = Failure Mode Identifier
KWP = Keyword Protocol
SPN
FMI
KWP
Description
524102
9
1674
Timeout error of CAN
-Receive-
Frame ComRxDPFBrnAirPmpCtl
524103
9
1675
Timeout error of CAN
-Receive-
Frame ComRxDPFBrnAirPmp
524104
9
1676
Timeout error
of CAN-Receive-
Frame ComRxDPFCtl
524105
9
1668
Timeout error of CAN
-Transmit-
Frame ComEGRMsFlw
524106
9
1677
Timeout error of CAN
-Receive-
Frame ComRxEGRMsFlw1
524107
9
1678
Timeout error of CAN
-Receive-
Frame ComRxEGRMsFlw2
524108
9
1669
Timeout error
of CAN-Transmit-
Frame ComEGRTVActr
524109
9
1679
Timeout error of CAN
-Receive-
Frame ComRxEGRTVActr
524110
9
1670
Timeout error of CAN
-Transmit-
Frame ComETVActr
524111
9
1680
Timeout error of CAN
-Receive-
Frame ComRxETVActr
524112
9
1671
Timeout
ComITVActr
524113
9
1681
Timeout error of CAN
-Receive-
Frame ComRxITVActr
SPN
FMI
KWP
Description
524114
9
1659
Timeout error of CAN
-Transmit-
Frame A1DOC
524115
9
1660
Timeout error of CAN
-Transmit-
Frame AT1S
524116
9
1661
Timeout error of
CAN-Transmit-
F
rame SCR2
524117
9
1662
Timeout error of CAN
-Transmit-
Frame SCR3
524118
9
1672
Timeout error of CAN
-Receive-
Frame ComRxCM1
524119
9
1673
Timeout error of CAN
-Receive-
Frame ComRxCustSCR3
524120
9
1682
Timeout error of
CAN-Receive-
Frame ComRxSCRHtDiag
5
24121
9
1683
Timeout error of CAN
-Receive-
Frame ComRxTrbChActr
524122
9
1684
Timeout error of CAN
-Receive-
Frame ComRxUQSens
524123
9
1685
Timeout error of CAN
-Receive-
Frame ComSCRHtCtl
524124
9
1686
Timeout error of
CAN-Receive-
Frame ComTxAT1IMG
524125
9
1687
Timeout error of CAN
-Receive-
Frame ComTxTrbChActr
