Ford MSG-425 Engine Fault Codes
Part No. 1306587GT GS
™
-84 • GS
™
-90 155
Code
Description
1629
J1939 TSC
1 message receipt lost
1630
J1939 ETC message receipt
lost
1631
PWM1
-Gauge1 open / ground short
1632
PWM1
-Gauge1 short to power
1633
PWM2
-Gauge2 open /ground short
1634
PWM2
-Gauge2 short to power
1635
PWM3
-Gauge3 open / ground short
1636
PWM3
-Gauge3 short to power
1641
Buzzer control ground shor
t
1642
Buzzer open
1643
Buzzer control short to power
1644
MIL control ground short
1645
MIL control short to power
2111
Unable to reach lower TPS
2112
Unable to reach higher TPS
2115
FPP
1 higher than IVS limit
2116
FPP
2 higher than IVS limit
2120
FPP
1 invalid voltage and FPP2 disagrees
with IVS
2121
FPP
1 lower than FPP2
2122
FPP
1 high voltage
2123
FPP
1 low voltage
2125
FPP
2 invalid voltage and FPP1 disagrees
with IVS
2126
FPP
1 higher than FPP2
2127
FPP
2 low voltage
2128
FPP
2 high voltage
Code
Description
2130
IVS stuck at
-idle, FPP1/2 match
2131
IVS stuck off
-idle, FPP1/2 match
2135
TPS1/
2 simultaneous voltages out of range
2139
FPP
1 lower than IVS limit
2140
FPP
2 lower than IVS limit
2229
BP high pressure
2300
Primary Loop Open or Low
-side Short to
Ground
2301
Primary Coil Shorted
2303
Primary Loop Open or Low
-side Short to
Ground
2304
Primary Coil Shorted
2306
Primary Loop Open or Low
-side Short to
Ground
2307
Primary Coil Shorted
For further engine fault code troubleshooting and
diagnostic information, refer to the Ford MSG-425
EFI Diagnostic Manual (EDI part number
1080030).
Ford MSG-425 EFI Diagnostic Manual
Genie part number
162067
