Texas Instruments DLP LightCrafter 4500 User Manual

What is in the LightCrafter 4500 EVM? www.ti.com
Figure 1-3. 0.45-Inch DMD Diamond Pixel Geometry
Figure 1-4. 0.45-Inch DMD Diamond Pixel Array Configuration
Figure 1-5. Diamond Pixel for Vertical, Horizontal, and Diagonal Lines
1.2.1.1 Light Engine Thermal Limits
The DLP LightCrafter 4500 is an actively cooled system with a thermal limit requiring that of all three
simultaneous LED currents is less than 4.3 A.
CAUTION
Do not overheat the system by driving all LEDs at maximum power.
12
DLP LightCrafter 4500 Module Overview DLPU011E–July 2013–Revised September 2015
Submit Documentation Feedback
Copyright © 2013–2015, Texas Instruments Incorporated
