JTAG Boundary Scan
www.ti.com
Table 7-10. FPD-Link Connector Pins (continued)
Description Pin Supply Range
RXE_EP 14 1.2 V
Ground 15 0 V
Ground 16 0 V
RXE_DN 17 1.2 V
RXE_EN 18 1.2 V
NC 19 N/A
NC 20 N/A
7.11 JTAG Boundary Scan
Table 7-11 lists the JTAG boundary connector (J25) pins. Two matching six-pin, 1.25-mm connector part
numbers are:
• Molex part number: 51021-0600
• Digi-Key part number: WM1724-ND
The corresponding connector terminal (crimp) part numbers are:
• Molex part number: 50079-8100
• Digi-Key part number: WM2023-ND
Table 7-11. JTAG Boundary Scan Connector Pins
Description Pin Supply Range
TRST 1 3.3 V
TDI 2 3.3 V
TMS1 3 3.3 V
TDO1 4 3.3 V
TCK 5 3.3 V
Ground 6 Ground
7.12 Power
Table 7-12 lists the power socket (J26) pins. Two matching connector part numbers are:
• Switchcraft part number: 760
• Digi-Key part number: SC1051-ND
Table 7-12. Power Connector Pins
Description Pin Supply Range
Input supply 1 12 V
Ground 2 0 V
Ground 3 0 V
68
Connectors DLPU011E–July 2013–Revised September 2015
Submit Documentation Feedback
Copyright © 2013–2015, Texas Instruments Incorporated
