What is in the LightCrafter 4500 EVM? www.ti.com
– TL7712: Programmable time delay for power-supply sequencing
• TFP401: Digital Receiver for DVI to 24-bit parallel RGB interface
• TS3USB2221A: ESD-protected high-speed USB multiplexer
• SN74AVC32T245: 32-bit dual supply bus transceiver for system board interface
1.2.3 Embedded Processor Interface
The DLP LightCrafter 4500 driver board allows the connection of a PandaBoard ES. See, Chapter 6.
1.3 Other Items Needed for Operation
The DLP LightCrafter 4500 module is a flexible, ready-to-use EVM. However, the DLP LightCrafter 4500
EVM does not ship with cables, power supply, or additional hardware components. To use the EVM, the
user needs the following:
• Power supply:
– Nominal voltage: 12-V DC
– Typical current: 6 A
– Maximum current: 7 A
– DC connector size:
• Inner diameter: 2.5 mm
• Outer diameter: 5.5 mm
• Shaft: 9.5-mm female, center positive
– Efficiency level: V
– A recommended power supply is Digi-Key part number 62-1186-ND , or equivalent.
• USB cable: A to mini-B USB cable
• Optional: PandaBoard 4500
14
DLP LightCrafter 4500 Module Overview DLPU011E–July 2013–Revised September 2015
Submit Documentation Feedback
Copyright © 2013–2015, Texas Instruments Incorporated
