7.6 Fan
Table 7-6 lists the fan connector (J22) pins. Two matching three-pin, 1.25-mm connector part numbers
are:
• Molex part number: 51021-0300
• Digi-Key part number: WM1722-ND
The corresponding terminal (crimp) part numbers are:
• Molex part number: 50079-8100
• Digi-Key part number: WM2023-ND
Table 7-6. Fan Connector Pins
Description Pin Supply Range
Power 1 12 V
FAN_LOCKED 2 3.3 V
Ground 3 0 V
7.7 Red LED
Table 7-7 lists the red LED connector (J31) pins. Two matching nine-pin, 1.5-mm connector part numbers
are:
• Molex part number: 87439-0900
• Digi-Key part number: WM2093-ND
The corresponding terminal (crimp) part numbers are:
• Molex part number: 87421-0000
• Digi-Key part number: WM1112-ND
Table 7-7. Red LED Connector Pins
Description Pin Supply Range
Ground 1 0 V
Temperature sensor 2 3.3 V
3.3-V supply 3 3.3 V
Red anode 4 3 V
Red anode 5 3 V
Red anode 6 3 V
Red cathode 7 0 V
Red cathode 8 0 V
Red cathode 9 0 V
7.8 Green LED
Table 7-8 lists the green LED connector (J32) pins. Two matching six-pin, 1.5-mm connector part numbers
are:
• Molex part number: 87439-0600
• Digi-Key part number: WM2093-ND
The corresponding terminal (crimp) part numbers are:
• Molex part number: 87421-0000
• Digi-Key part number: WM1112-ND
