www.ti.com Blue LED
Table 7-8. Green LED Connector Pins
Description Pin Supply Range
Green anode 1 4.3 V
Green anode 2 4.3 V
Green anode 3 4.3 V
Green cathode 4 0 V
Green cathode 5 0 V
Green cathode 6 0 V
7.9 Blue LED
Table 7-9 lists the blue LED connector (J33) pins. Two matching six-pin, 1.5-mm connector part numbers
are:
• Molex part number: 87439-0600
• Digi-Key part number: WM2093-ND
The corresponding terminal (crimp) part numbers are:
• Molex part number: 87421-0000
• Digi-Key part number: WM1112-ND
Table 7-9. Blue LED Connector Pins
Description Pin Supply Range
Blue anode 1 4.3 V
Blue anode 2 4.3 V
Blue anode 3 4.3 V
Blue cathode 4 0 V
Blue cathode 5 0 V
Blue cathode 6 0 V
7.10 FPD-Link
Table 7-10 lists the FPD-Link connector (J9) pins. The 20-pin, 0.5 SMT header is:
• Panasonic part number: AXK6S20647YG
Table 7-10. FPD-Link Connector Pins
Description Pin Supply Range
RCK_IN_P 1 1.2 V
RXE_AP 2 1.2 V
Ground 3 0 V
Ground 4 0 V
RCK_IN_N 5 1.2 V
RXE_AN 6 1.2 V
RXE_BP 7 1.2 V
RXE_CP 8 1.2 V
Ground 9 0 V
Ground 10 0 V
RXE_BN 11 1.2 V
RXE_CN 12 1.2 V
RXE_DP 13 1.2 V
67
DLPU011E–July 2013–Revised September 2015 Connectors
Submit Documentation Feedback
Copyright © 2013–2015, Texas Instruments Incorporated
