Appendix B
DLPU011E–July 2013–Revised September 2015
Power Supply Requirements
B.1 External Power Supply Requirements
The DLP LightCrafter 4500 does not include a power supply. The external power supply requirements are:
• Nominal voltage: 12-V DC
• Minimum current: 0 A
• Maximum Current: 7 A
• DC connector size:
– Inner diameter: 2.5 mm
– Outer diameter: 5.5 mm
– Shaft: 9.5-mm female, center positive
• Efficiency level: V
NOTE: External Power Supply Regulatory Compliance Certifications: Recommend selection and use
of an external power supply, which meets TI’s required minimum electrical ratings in addition
to complying with applicable regional product regulatory and safety certification requirements
such as (by example) UL, CSA, VDE, CCC, PSE, and so forth.
