www.ti.com
Pattern Sequence Background
Table 4-1 lists the allowed pattern combinations in relation to the bit depth of the external pattern.
Table 4-1. Allowable Pattern Combinations
Maximum
External RGB Number of
Preloaded Minimum Pattern
Bit Depth Input Pattern Patterns using
Pattern Rate (Hz) Exposure Period (µs)
Rate (Hz) Two Buffers
(PreLoaded)
1 bit 2880 4225 235 48
2 bits 1428 1428 700 24
3 bits 636 636 1570 16
4 bits 588 588 1700 12
5 bits 480 500 2000 8
6 bits 400 400 2500 8
7 bits 222 222 4500 6
8 bits 120 120 8333 6
49
DLPU011E–July 2013–Revised September 2015 Pattern Sequences
Submit Documentation Feedback
Copyright © 2013–2015, Texas Instruments Incorporated
