Chapter 1
DLPU011E–July 2013–Revised September 2015
DLP LightCrafter 4500 Module Overview
1.1 Welcome
The DLP LightCrafter 4500 evaluation module (EVM) allows evaluation of the DLP 4500 platform from TI.
This technology brings together a set of components providing an efficient and compelling system solution
for:
• 3D scanning structured light applications:
– 3D modeling and design
– Fingerprint identification and face recognition
– Machine vision and robotic factory automation
– Industrial inspection
• Medical and life sciences:
– Vascular imaging
– Hyperspectral imaging
– Dental impression scanners
– Intraoral dental scanners
– Orthopedics, prosthesis, CT, MRI, and X-ray marking
– Retail cosmetics
• Small display projectors:
– Embedded display
– Interactive display
– Information overlay
• Spectroscopy and chemical sensing
– Material identification
– Oil & Gas analysis
– Water & air quality
– Food & drug inspection
– TI NIRscan EVM uses the DLP4500NIR DMD (similar to the DLP4500 in the LightCrafter4500 EVM
and optimized for near-infrared light) in structured light mode to provide a high performance and
cost-competitive spectroscopy solution
1.2 What is in the LightCrafter 4500 EVM?
The DLP LightCrafter 4500 module consists of two subsystems:
• Light engine – includes the optics; red, green, and blue LEDs; and the 912 × 1140 diamond pixel 0.45-
inch WXGA DMD, heat sinks, and fan. The light engine produces approximately 150 lumens at 15-W
LED power consumption.
• Driver board – includes the LED driver circuits, DLPC350 DMD controller, power-management circuits,
DVI-to-RGB conversion with the TFP401, and a 32-MB flash storage
Figure 1-1 shows the major hardware components.
