TMS570LS0714
www.ti.com SPNS226E –JUNE 2013–REVISED NOVEMBER 2016
Table 7-21. MibADC2 Event Trigger Hookup
GROUP SOURCE SELECT
(G1SRC, G2SRC, OR EVSRC)
EVENT NO.
TRIGGER EVENT SIGNAL
PINMMR30[0] = 1
(DEFAULT)
PINMMR30[0] = 0 and PINMMR30[1] = 1
OPTION A
CONTROL FOR
OPTION A
OPTION B
CONTROL FOR
OPTION B
000 1 AD2EVT AD2EVT — AD2EVT —
001 2 N2HET1[8] N2HET2[5] PINMMR31[16] = 1 ePWM_B
PINMMR31[16] = 0 and
PINMMR31[17] = 1
010 3 N2HET1[10] N2HET1[27] — N2HET1[27] —
011 4 RTI Compare 0 Interrupt RTI Compare 0 Interrupt PINMMR31[24] = 1 ePWM_A1
PINMMR31[24] = 0 and
PINMMR31[25] = 1
100 5 N2HET1[12] N2HET1[17] — N2HET1[17] —
101 6 N2HET1[14] N2HET1[19] PINMMR32[0] = 1 N2HET2[1]
PINMMR32[0] = 0 and
PINMMR32[1] = 1
110 7 GIOB[0] N2HET1[11] PINMMR32[8] = 1 ePWM_A2
PINMMR32[8] = 0 and
PINMMR32[9] = 1
111 8 GIOB[1] N2HET2[13] PINMMR32[16] = 1 ePWM_AB
PINMMR32[16] = 0 and
PINMMR32[17] = 1
