(1) 1 LSB = (AD
REFHI
– AD
REFLO
)/ 2
12
for 12-bit mode
(2) 1 LSB = (AD
REFHI
– AD
REFLO
)/ 2
10
for 10-bit mode
Table 7-26. MibADC Operating Characteristics Over Full Ranges of Recommended Operating
Conditions
(1)(2)
PARAMETER DESCRIPTION/CONDITIONS MIN NOM MAX UNIT
CR
Conversion range over which
specified accuracy is maintained
AD
REFHI
– AD
REFLO
3 5.25 V
Z
SET
Zero Scale Offset
Difference between the first ideal transition (from
code 000h to 001h) and the actual transition
10-bit mode 1
LSB
12-bit mode 2
F
SET
Full Scale Offset
Difference between the range of the measured
code transitions (from first to last) and the range of
the ideal code transitions
10-bit mode 2
LSB
12-bit mode 3
E
DNL
Differential nonlinearity error
Difference between the actual step width and the
ideal value (see Figure 7-13).
10-bit mode ± 1.5
LSB
12-bit mode ± 2
E
INL
Integral nonlinearity error
Maximum deviation from the best straight line
through the MibADC. MibADC transfer
characteristics, excluding the quantization error.
10-bit mode ± 2
LSB
12-bit mode ± 2
E
TOT
Total unadjusted error
Maximum value of the difference between an
analog value and the ideal midstep value.
10-bit mode ± 2
LSB
12-bit mode ± 4
