4.2.1.2 Enhanced High-End Timer (N2HET) Modules
Table 4-2. PGE Enhanced High-End Timer (N2HET) Modules
TERMINAL
SIGNAL
TYPE
RESET
PULL
STATE
PULL TYPE
DESCRIPTION
SIGNAL NAME
144
PGE
N2HET1[0]/SPI4CLK/EPWM2B 25
I/O
Pulldown
Programmable,
20 µA
N2HET1 timer input
capture or output
compare, or GIO.
Each terminal has a
suppression filter with a
programmable duration.
N2HET1[01]/SPI4NENA/N2HET2[8]/EQEP2A 23
N2HET1[02]/SPI4SIMO[0]/EPWM3A 30
N2HET1[03]/SPI4NCS[0]/N2HET2[10]/EQEP2B 24
N2HET1[04]/EPWM4B 36
N2HET1[05]/SPI4SOMI[0]/N2HET2[12]/EPWM3B 31
N2HET1[06]/SCIRX/EPWM5A 38
N2HET1[07]/N2HET2[14]/EPWM7B 33
N2HET1[08]/MIBSPI1SIMO[1]/ 106
N2HET1[09]/N2HET2[16]/EPWM7A 35
N2HET1[10]/nTZ3 118
N2HET1[11]/MIBSPI3NCS[4]/N2HET2[18]/EPWM1SYNCO 6
N2HET1[12] 124
N2HET1[13]/SCITX/EPWM5B 39
N2HET1[14] 125
N2HET1[15]/MIBSPI1NCS[4]/ECAP1 41
N2HET1[16]/EPWM1SYNCI/EPWM1SYNCO 139
MIBSPI1NCS[1]/N2HET1[17]/EQEP1S 130 Pullup
N2HET1[18]/EPWM6A 140 Pulldown
MIBSPI1NCS[2]/N2HET1[19] 40 Pullup
N2HET1[20]/EPWM6B 141
Pulldown
N2HET1[22] 15
MIBSPI1NENA/N2HET1[23]/ECAP4 96 Pullup
N2HET1[24]/MIBSPI1NCS[5] 91 Pulldown
MIBSPI3NCS[1]/N2HET1[25] 37 Pullup
N2HET1[26] 92 Pulldown
MIBSPI3NCS[2]/I2CSDA/N2HET1[27]/nTZ2 4 Pullup
N2HET1[28] 107 Pulldown
MIBSPI3NCS[3]/I2CSCL/N2HET1[29]/nTZ1 3 Pullup
N2HET1[30]/EQEP2S 127 Pulldown
MIBSPI3NENA/MIBSPI3NCS[5]/N2HET1[31]/EQEP1B 54 Pullup
GIOA[5]/EXTCLKIN1/EPWM1A/N2HET1_PIN_nDIS 14 Pulldown
Disable selected PWM
outputs
GIOA[2]/N2HET2[0]/EQEP2I 9
I/O
Pulldown
Programmable,
20 µA
N2HET2 timer input
capture or output
compare, or GIO
Each terminal has a
suppression filter with a
programmable duration.
GIOA[6]/N2HET2[4]/EPWM1B 16
GIOA[7]/N2HET2[6]EPWM2A 22
N2HET1[01]/SPI4NENA//N2HET2[8] 23
N2HET1[03]/SPI4NCS[0]/N2HET2[10]/EQEP2B 24
N2HET1[05]/SPI4SOMI[0]/N2HET2[12]/EQEP3B 31
N2HET1[07]/N2HET2[14]/EPWM7B 33
N2HET1[09]/N2HET2[16] 35
N2HET1[11]/MIBSPI3NCS[4]/N2HET2[18]/EPWM1SYNCO 6
MIBSPI3NCS[0]/AD2EVT/GIOB[2]/EQEP1l/N2HET2_PIN_nDIS 55 Pullup
Disable selected PWM
outputs
