(1) These signals, when used as inputs, are double-synchronized and then optionally filtered with a 6-cycle VCLK4-based counter.
4.2.1.3 Enhanced Capture Modules (eCAP)
Table 4-3. PGE Enhanced Capture Modules (eCAP)
(1)
TERMINAL
SIGNAL
TYPE
RESET
PULL
STATE
PULL TYPE DESCRIPTION
SIGNAL NAME
144
PGE
N2HET1[15]/MIBSPI1NCS[4]/ECAP1 41
I/O
Pulldown
Fixed, 20 µA
Enhanced Capture Module 1
I/O
MIBSPI3SOMI[0]/AWM1_EXT_ENA/ECAP2 51
Pullup
Enhanced Capture Module 2
I/O
MIBSPI3SIMO[0]/AWM1_EXT_SEL[0]/ECAP3 52
Enhanced Capture Module 3
I/O
MIBSPI1NENA/N2HET1[23]/ECAP4 96
Enhanced Capture Module 4
I/O
MIBSPI5NENA/MIBSPI5SOMI[1]/ECAP5 97
Enhanced Capture Module 5
I/O
MIBSPI1NCS[0]/MIBSPI1SOMI[1]/ECAP6 105
Enhanced Capture Module 6
I/O
(1) These signals are double-synchronized and then optionally filtered with a 6-cycle VCLK4-based counter.
4.2.1.4 Enhanced Quadrature Encoder Pulse Modules (eQEP)
Table 4-4. PGE Enhanced Quadrature Encoder Pulse Modules (eQEP)
(1)
TERMINAL
SIGNAL
TYPE
RESET
PULL
STATE
PULL TYPE DESCRIPTION
SIGNAL NAME
144
PGE
MIBSPI3CLK/AWM1_EXT_SEL[1]/EQEP1A 53 Input
Pullup
Fixed, 20 µA
Enhanced QEP1 Input A
MIBSPI3NENA/MIBSPI3NCS[5]/N2HET1[31]/EQEP1B 54 Input Enhanced QEP1 Input B
MIBSPI3NCS[0]/AD2EVT/GIOB[2]/EQEP1I/N2HET2_PIN_nDIS 55 I/O Enhanced QEP1 Index
MIBSPI1NCS[1]/N2HET1[17]//EQEP1S 130 I/O Enhanced QEP1 Strobe
N2HET1[01]/SPI4NENA/N2HET2[8]/EQEP2A 23 Input
Pulldown
Enhanced QEP2 Input A
N2HET1[03]/SPI4NCS[0]/N2HET2[10]/EQEP2B 24 Input Enhanced QEP2 Input B
GIOA[2]/N2HET2[0]/EQEP2I 9 I/O Enhanced QEP2 Index
N2HET1[30]/EQEP2S 127 I/O Enhanced QEP2 Strobe
