4.2.1.5 Enhanced Pulse-Width Modulator Modules (ePWM)
Table 4-5. PGE Enhanced Pulse-Width Modulator Modules (ePWM)
TERMINAL
SIGNAL
TYPE
RESET
PULL
STATE
PULL TYPE DESCRIPTION
SIGNAL NAME
144
PGE
GIOA[5]/EXTCLKIN1/EPWM1A/N2HET1_PIN_nDIS 14
Output Pulldown –
Enhanced PWM1 Output A
GIOA[6]/N2HET2[4]/EPWM1B 16 Enhanced PWM1 Output B
N2HET1[11]/MIBSPI3NCS[4]/N2HET2[18]/EPWM1SYNCO 6
External ePWM Sync Pulse
Output
N2HET1[16]/EPWM1SYNCI/EPWM1SYNCO 139 Input Pullup Fixed, 20 µA
External ePWM Sync Pulse
Output
GIOA[7]/N2HET2[6]/EPWM2A 22
Output Pulldown –
Enhanced PWM2 Output A
N2HET1[0]/SPI4CLK/EPWM2B 25 Enhanced PWM2 Output B
N2HET1[02]/SPI4SIMO[0]/EPWM3A 30 Enhanced PWM3 Output A
N2HET1[05]/SPI4SOMI[0]/N2HET2[12]/EPWM3B 31 Enhanced PWM3 Output B
MIBSPI5NCS[0]/EPWM4A 32 Output Pullup – Enhanced PWM4 Output A
N2HET1[04]/EPWM4B 36
Output Pulldown –
Enhanced PWM4 Output B
N2HET1[06]/SCIRX/EPWM5A 38 Enhanced PWM5 Output A
N2HET1[13]/SCITX/EPWM5B 39 Enhanced PWM5 Output B
N2HET1[18]/EPWM6A 140 Enhanced PWM6 Output A
N2HET1[20]/EPWM6B 141 Enhanced PWM6 Output B
N2HET1[09]/N2HET2[16]/EPWM7A 35 Enhanced PWM7 Output A
N2HET1[07]/N2HET2[14]/EPWM7B 33 Enhanced PWM7 Output B
MIBSPI3NCS[3]/I2CSCL/N2HET1[29]/nTZ1 3
Input
Pullup
Fixed, 20 µA
Trip Zone Inputs 1, 2 and 3.
These signals are either
connected asynchronously to
the ePWMx trip zone inputs,
or double-synchronized with
VCLK4, or double-
synchronized and then filtered
with a 6-cycle VCLK4-based
counter before connecting to
the ePWMx trip zone inputs.
MIBSPI3NCS[2]/I2CSDA/N2HET1[27]/nTZ2 4
N2HET1[10]/nTZ3 118 Pulldown
