Page #16 background imageLoading...
Page #16 background image
16
TMS570LS0714
SPNS226E JUNE 2013REVISED NOVEMBER 2016
www.ti.com
Submit Documentation Feedback
Product Folder Links: TMS570LS0714
Terminal Configuration and Functions Copyright © 2013–2016, Texas Instruments Incorporated
(1) GIOB[2] cannot output a level on to pin 55. Only the input functionality is supported so that the application can generate an interrupt
whenever the N2HET2_PIN_nDIS is asserted (driven low). Also, a pullup is enabled on the input. This is not programmable using the
GIO module control registers.
4.2.1.6 General-Purpose Input/Output (GIO)
Table 4-6. PGE General-Purpose Input/Output (GIO)
Terminal
Signal
Type
Reset Pull
State
Pull Type Description
Signal Name 144 PGE
GIOA[0] 2
I/O
Pulldown
Programmable,
20 µA
General-purpose I/O.
All GIO terminals are
capable of generating
interrupts to the CPU
on rising / falling /
both edges.
GIOA[1] 5
GIOA[2]/N2HET2[0]/EQEPII 9
GIOA[5]/EXTCLKIN1/EPWM1A/N2HET1_PIN_nDIS 14
GIOA[6]/N2HET2[4]/EPWM1B 16
GIOA[7]/N2HET2[6]/EPWM2A 22
GIOB[0] 126
GIOB[1] 133
GIOB[2] 142
MIBSPI3NCS[0]/AD2EVT/GIOB[2]/EQEP1I/N2HET2_PIN_nDIS 55
(1)
Pullup
GIOB[3] 1 Pulldown
4.2.1.7 Controller Area Network Controllers (DCAN)
Table 4-7. PGE Controller Area Network Controllers (DCAN)
Terminal Signal
Type
Reset Pull
State
Pull Type Description
Signal Name 144
PGE
CAN1RX 90 I/O Pullup Programmable,
20 µA
CAN1 receive, or GIO
CAN1TX 89 CAN1 transmit, or GIO
CAN2RX 129 CAN2 receive, or GIO
CAN2TX 128 CAN2 transmit, or GIO
CAN3RX 12 CAN3 receive, or GIO
CAN3TX 13 CAN3 transmit, or GIO
4.2.1.8 Local Interconnect Network Interface Module (LIN)
Table 4-8. PGE Local Interconnect Network Interface Module (LIN)
Terminal Signal
Type
Reset Pull
State
Pull Type Description
Signal Name 144
PGE
LINRX 131 I/O Pullup Programmable,
20 µA
LIN receive, or GIO
LINTX 132 LIN transmit, or GIO
