THERMACUT EX-TRAFIRE 45HD - Setting up the Power Supply; Connecting to the Gas Supply; Connecting the Work Lead

EN - 16
6 Setting up the power supply EX-TRAFIRE
®
45HD
6 Setting up the power supply
6.1 Connecting to the gas supply
6.2 Connecting the work lead
 Connect the gas hose with an inside
diameter of at least 6 mm to the gas
connection of the device.
Single-phase
Three-phase
 Connect the work lead to the work
lead connecting socket and secure it
by rotating clockwise.
