THERMACUT EX-TRAFIRE 45HD - Cutting, Shielded, with Compressed Air

EN - 56
19 Cutting tables for mechanical cutting EX-TRAFIRE
®
45HD
19.1 30 A cutting, shielded, with compressed air
EX-2-401-201EX-2-404-201EX-2-409-201EX-2-415-202
EX-2-415-201
EX-2-423-211
EX-2-421-201
EX-2-428-011
Material
thickness
Torch
(shield) to
workpiece
distance
Pierce
height
(shield) to
workpiece
distance
Pierce delay
time
Recommended
speed
Maximum speed Kerf
width
Settings for
highest quality
Standard quality
settings
Cutting
speed
Voltage Cutting
speed
Voltage
[mm] [mm] [mm] [Seconds] [mm/min] [Volts] [mm/min] [Volts] [mm]
Mild steel
0.5
1.5 3.8
0
9150 117 10160 107 0.9
0.8 8650 116 10160 109 1
1 8100 115 10160 113 1
1.5 0.2 5650 111 7100 115 1.1
Stainless steel
0.5
1.5 3.8
0
9150 119 10160 123 1
0.8 8650 117 10160 121 1
1 8100 115 10160 119 1.1
1.5 0.2 3750 113 4700 118 1.3
Aluminum
1.2
1.5 3.8
0 9150 117 10160 120 1.2
1.5
0.2
8650 118 10160 121 1.2
2 5450 118 6860 121 1.3
