THERMACUT EX-TRAFIRE 45HD - Technical Data; EX-TRAFIRE 45 HD, Single-Phase

EX-TRAFIRE
®
45HD 4 Product description
EN - 11
4.2 Technical data
4.2.1 EX-TRAFIRE
®
45HD, Single-phase
Table 1 Power supply specifications, single-phase
CE
Idle voltage (U
0
) 292 V DC
Characteristic curve*
* The curve is defined as output voltage
versus output current
Drooping
Output current (I
2
) 10 – 45 A
Nominal voltage (U
2
) 145 V DC
Output current at 100% duty cycle (I
2
) 16 A
Maximum power input 7.5 kVA
Duty cycle (X*) at 40°C under nominal
conditions (U
1
, I
1
, U
2
, I
2
)
*X = t
on
/t
base
t
on
= time, minutes
t
base
=10 minutes
U
1rms
40%
Ambient temperature -10° to +40°C
Input voltage (U
1
) 240 V AC ± 15%
Rated input current (I
1rms
) and effective
input current (I
1eff
) at rated output
voltage (U
2
) and rated output current
(I
2
) - only for cutting mode.
eff= effective
rms= root mean square
I
1rms I1eff
16.5 A 14.8 A
Complies with standards IEC
60974-1,
IEC 60974-10
Insulation class F
Protection type IP23S
Tilt angle (with or without wheels) Up to15°
Dimensions (L×H×W)
[mm] 469.9 x 228.6 x 177.0
Weight (kg) 12.7
