4 Product description
4.1 Assembly and use
The control elements are located on the control panel. The connections are
on the front and rear of the device.
Fig. 2 Control elements and connections, rear panel
A On/Off switch
B Optional CNC interface
C G1/4" gas connection, plug
D Optional BUS interface
E Input power cable
Fig. 3 Control elements and connections, front panel
F Work lead connection
G Torch connection system (TCS)
H Multi-function button
I Display
A B
C
DE
Single-phase
CE
A
DB
Three-phase
F
G
H
I
