EX-TRAFIRE
®
45HD 6 Setting up the power supply
EN - 23
6.7 Installing consumables for the hand and machine
cutting torches
Risk of injury due to unexpected ignition of the plasma arc
Hand cutting torch:
When the input power plug is plugged in, the plasma arc ignites
immediately when the torch trigger is pressed. Individuals can be
seriously injured if the arc ignites unexpectedly.
Machine cutting torch:
When the input power plug is plugged in, the plasma arc ignites
immediately when the CNC start signal is ON. Individuals can be
seriously injured if the arc ignites unexpectedly.
• Hold the tip of the torch away from you.
• Do not hold the workpiece to be cut tightly and keep your hands away
from the cutting surface.
• Do not point the cutting torch at yourself or other individuals.
• Wear your personal protective equipment.
A Shield
B Retaining cap
C Nozzle
D Swirl ring
E Electrode
F Hand cutting torch / Machine cutting
torch
A BC D E F
Hand cutting torch
A BC D E F
Machine cutting torch
