45TTM machine cutting torch unit EX-TRAFIRE
®
45HD
17 FHT-EX
®
45TTM machine cutting torch unit
17.1 FHT-EX
®
45TTM machine cutting torch components
Table 19 FHT-EX
®
45TTM machine cutting torch
Part number Description
EX-2-233-001 FHT-EX
®
45TTM DEMO machine cutting torch with
consumables/TCS13
EX-2-202-001 FHT-EX
®
45TTM machine cutting torch without
consumables, with 5 m (16.5‘) lead/TCS13
EX-2-204-001 FHT-EX
®
45TTM machine cutting torch without
consumables, with 8 m (26‘) lead/TCS13
EX-2-207-001 FHT-EX
®
45TTM machine cutting torch without
consumables, with 15 m (50‘) lead/TCS13
A BCD EFG H
I
J
K
P
O
N
M
Lc Lb La
L
