THERMACUT EX-TRAFIRE 45HD - Page 49

EX-TRAFIRE
®
45HD 17 FHT-EX
®
45TTM machine cutting torch unit
EN - 49
Table 20 Machine cutting torch components
Item Part number Description
A EX-0-325-005 Male crimp pin for TCS plug
B EX-0-325-009 O-ring (fitted in the TCS plug)
C EX-0-325-010 Retaining ring (outer circlip ring)
D EX-0-323-001 TCS13 plug body
E EX-0-325-001 TCS clam shell lower
F EX-0-325-002 TCS clam shell upper
G EX-0-325-015 TCS clam shell screw
H EX-5-318-001 TCS plug spring strain relief
I
EX-2-352-001 FHT-EX
®
45TTM machine torch lead
replacement kit 5 m lead/TCS13
EX-2-354-001 FHT-EX
®
45TTM machine torch lead
replacement kit 8 m lead/TCS13
EX-2-357-001 FHT-EX
®
45TTM machine torch lead
replacement kit 15 m lead/TCS13
J EX-5-317-021 Machine torch strain relief
K EX-2-306-001 FHT-EX
®
45TTM standard mounting tube
without rack
L EX-2-301-001 Machine torch body assembly
FHT-EX
®
45TTM consisting of La, Lb, Lc
La EX-2-301-002 Cap sensor replacement kit with screws/
machine torch
Lb EX-5-304-001 Machine torch body FHT-EX
®
45TTM
Lc EX-5-306-002 Torch mounting sleeve (incl. 3 screws)
M EX-5-372-005 Torch mounting screws kit (incl. 3 screws)
N EX-5-431-050 O-ring (fitted on the torch body) -
2pcs per package
O EX-5-372-010 Cathode mounting kit
P EX-0-321-003 Latch w/Key Assembly
