45TTH hand cutting torch unit EX-TRAFIRE
®
45HD
Table 17 Components for hand cutting torch 45 A and gouging
Hand cutting torch
Item Part number Description
A EX-0-325-005 Male crimp pin for TCS plug
B EX-0-325-009 O-Ring (fitted in the TCS plug)
C EX-0-325-010 Retaining ring (outer circlip ring)
D EX-0-323-001 TCS13 plug body
E EX-0-325-001 TCS clam shell lower
F EX-0-325-002 TCS clam shell upper
G EX-0-325-015 TCS clam shell screw
H EX-5-318-001 TCS plug spring strain relief
I
EX-2-331-001
FHT-EX
®
45TTH hand torch lead replacement
kit 5 m lead/TCS13
EX-2-333-001
FHT-EX
®
45TTH hand torch lead replacement
kit 8 m lead/TCS13
EX-2-336-001
FHT-EX
®
45TTH hand torch lead replacement
kit 15 m lead/TCS13
J EX-2-314-001
FHT-EX
®
45TTH hand torch handle
replacement kit consisting of
components K, L, M
K EX-2-313-001 Safety trigger with start switch
L EX-2-308-001 Hand torch handle with screws
M EX-2-305-001
Cap sensor replacement kit with screws/ hand
torch
N EX-5-431-050 O-ring (fitted on the torch body)
O EX-2-302-001 Hand torch body FHT-EX
®
45TTH
P EX-5-372-010 Cathode mounting kit
Q EX-0-321-003 Latch w/Key Assembly
